Parker排气过渡接头
Parker Bleeding Hydraulic Systems with Parker Bleed Adapters
Parker Bleed Adapters

派克的排气过渡接头可以为液压系统排气，而无须峰值压力连接。派克的排气过渡接头是专门为O形圈端面密封（ORFS）安装形式或者SAE、NPT螺纹阀块以及需要经常排气的阀而设计的。排气过渡接头适用于需要进行排气的液压系统中，这种应用下，使用传统的管路断开方式排气，可能会因为高压而将密封件冲出或者破坏。Parker's Bleed Adapters allow for bleeding hydraulic systems without "cracking" hydraulic connections.Parker's Bleed Adapters are designed specifically for installation directly to O-ring Face Seal (ORFS) type fittings or into SAE or NPT manifolds and valves where bleeding is often required. Bleed adapters are especially beneficial in hydraulic system applications where elastomeric seals can be extruded and/or damaged during bleeding done by "cracking" a connection.

Parker排气过渡接头
Parker Bleeding Hydraulic Systems with Parker Bleed Adapters

市场：:
- 建筑机械
- 农业机械
- 矿山机械
- 油/气
- 运输
- 可替代燃料

特征/优势：:
- 采用汽车行业标准排气螺钉设计，与本体永久性扣压在一起，防止脱落。
- 易于无须峰值液压系统的排气，防止大尺寸的接头可能产生的高压力或者弹性密封挤出或损坏产生的峰值压力:
- 排气接头可以有两种连接形式，与油口连接可以选择SAE和NPT外螺纹，与钢管或者软管连接可以选择外螺纹或者内螺纹ORFS接头。
- 适用于工作压力达12,000 psi的钢材质，尺寸可从1 1/4"到1 ?"

性能特点

最大静态压力 (PSI) 6500 至 12000
最大动态压力 (PSI) 5000 至 9200
连接 2 样式 SAE-ORB 尺寸 7/16-20 和 NPTF 尺寸 1/4-18
主体材料 碳钢，无六价铬镀锌
连接类型 排气过渡接头

应用:
- 液压连接Hydraulic fluid handling connections
